Name: Takeuchi TB257FR Excavator
Brand: Takeuchi
SKU: TB257FR

Whether you're digging foundations or building communities, our reliable equipment delivers precision for construction work. Select from top brands like Komatsu, BOMAG, and Takeuchi, plus custom attachments to ensure you have the right tools for the job.

Balancing economic harvesting with sustainable forest management is key to preservation. With rugged, purpose-built forestry equipment from TimberPro and Komatsu, you can manage just that. Our team is ready to assist you no matter how remote your site is.

Dense urban areas can limit your ability to work efficiently, but our compact solutions from trusted brands like Takeuchi can help you navigate tightly confined spaces with the horsepower you require.

Takeuchi

TB257FR

The TB257FR is the latest addition to the Takeuchi FR line up and features the same Side-to-Side (STS) boom configuration and minimal swing radius as the TB280FR. Powering the TB257FR is the Kubota V2403-CR-TE5B turbocharged engine that is U.S. EPA Tier 4 Final compliant and provides 32% more engine output than it’s predecessor, the TB153FR. Hydraulic performance is also improved with a 19% increase in traction force as well as hydraulic flow and main system pressure. The unique Side-to-Side (STS) boom configuration is what sets the TB257FR apart from is competition. The STS boom configuration and minimal tail swing allows for unmatched visibility and maneuverability when working in confined spaces. This configuration allows the upper structure to be full rotated nearly within the width of the tracks when the boom is stowed in the full upright position.

Emission Rating

Tier 4 Final

Net Horsepower

52.3 HP @2,200 rpm (39 kW @2,200 rpm)

Max Operating Weight

12930 lb (5865 kg)

Max Digging Depth

12′9″ (6080 mm)

Download TB257FR Brochure

Features

- 2 Year Standard Service
- Minimize Downtime
- Remote Diagnostics
- Utilization Tracking
- Proactive Maintenance
- Control Costs
- Geofencing

- Triple Flange Track Rollers
- 2-Speed Axial Piston Travel Motors with Counterbalance Valves
- Integrated Load Sensing, Automatic Downshift
- Automatic Fail-Safe Mechanical Parking Brake
- High Torque Planetary Final Drives
- Automatic Slew Brake with Shockless
- Relief Valve
- Concealed in Frame Travel Motor Connections
- Heavy Duty Backfill Blade with Float
- Large Wrap Around Protective Counterweight
- 15.7” Rubber Tracks
- 15.7” Steel Tracks (Optional)

- ROPS/OPG (Top Guard, Level I) Four Post Canopy
- Pressurized Cab with A/C, Heat, Defrost, Windshield Wiper and Washer, Skylight with Sunshade, AM/FM/MP3 Bluetooth Radio (Cab Only)
- Multifunction LCD Display (Canopy)
- 5.7” Color Multifunction Display (Cab)
- Sealed Rocker Switches
- Multifunction Joystick Controls
- Hand Dial Electronic Throttle Control
- Deluxe High Back Suspension Seat
- Pilot Control Safety Lockout System
- Adjustable Arm Rest
- Removable/Washable Floor Mat
- Cup Holder
- 12 Volt Power Socket
- 2” Retractable Seat Belt
- 3” Retractable Seat Belt (Optional)

- Variable Displacement Axial Piston Hydraulic Pump with Tandem Gear Pumps
- Cushioned Boom and Offset Cylinders
- STS (Side to Side) Shift Boom Design
- Boom Holding Valve with Lift Overload Alarm
- Hydraulic Pilot Controls
- Primary and Secondary Hydraulic
- Circuits Plumbed to Mid-Arm Shutoff Valves
- Proportional Primary and Secondary Auxiliary Circuit Controls
- Primary Auxiliary Detent Feature
- Auxiliary Flow Adjustable From Monitor
- Automatic One-Way Flow Valve for Primary Auxiliary Circuit
- Automatic Auxiliary Circuit Pressure Release Feature
- Hydraulic Reservoir with Fluid Level Sight Gauge
- LED Work Lights
- Travel Alarm
- Multiple Attachment Presets
- Integrated Hydraulic Quick Coupler
Control System (Quick Coupler Optional)
- Primary Auxiliary Circuit Flow Selector Valve
- Pilot Control Pattern Change Valve (ISO or SAE)
- Pilot Pressure Accumulator
- Main Boom Cylinder Guard
- Long Arm with Integrated Thumb Mount
- Dual Pin Position Bucket (Optional)
- Mechanical Bucket Quick Coupler (Optional)
- Hydraulic Pin Grabber Quick Coupler (Optional)
- Main Pin Hydraulic Thumb (Optional)

- U.S. EPA Tier 4 Final / EU Stage V
- Turbocharged Diesel
- Electronic Fuel Injection
- DOC+DPF Exhaust After Treatment
- Automatic Fuel Priming System
- Dual Element Air Cleaner
- Automatic Engine Idle Feature
- Working Modes: Standard, ECO, and High Altitude
- Automatic Cold Start Device
- High Capacity Radiator and Hydraulic Oil Cooler
- Engine Safe Start System
- 90 Amp Alternator
