Name: Komatsu D71PX-24 Dozer
Brand: Komatsu
SKU: D71PX-24

From top brands like Komatsu and Takeuchi, we have new equipment for all your project needs. Discover our range of solutions all backed by our commitment to your success.

Whether you’re looking for concrete pulverizers or harvesting heads, we’re proud to offer a complete range of attachments that meet your needs — as well as your standards.

Your source for aftermarket and OEM parts in Alaska.
We provide support for all areas of your equipment, including powertrain, hydraulic systems, lighting, operator environment, undercarriage, electrical systems, cooling systems and more.

Komatsu

D71PX-24

At home from golf course construction to highway projects. An all-around crawler dozer equally adept at precise, high-speed grading and rough dozing, designed to provide outstanding wearability and functionality with high-capacity, wear-resistant dozer blade.

Emission Rating

Tier 4 Final

Net Horsepower

237 HP @2,100 rpm (177 kW @2,100 rpm)

Max Operating Weight

50927 lb (23100 kg)

Blade Capacity

6.1 yd³ (4.65 m³)

Download D71PX-24 Brochure

Features

Outstanding visibility to the cutting edges and excellent balance and maneuverability with a super-slant nose cab-forward design.

Smooth, powerful turns with hydrostatic steering. Fully electronic control provides complete automatic shifting and allows for Quick-Shift or variable speed selection.

In P mode, the engine outputs its full power to help your operator perform heavy-load work. It automatically increases engine speed for maximum power when load increases. H mode increases engine high idle speed, suitable for power-intensive work.

Flexibility to adapt to various situations and the ability to be efficient and productive regardless of the terrain with a versatile 6-way PAT (power angle tilt) blade pitch system.

Easy access to the radiator, oil cooler and charge air cooler with swing-up assisted lift system. Hydraulic fan reverses for clearing objects restricting air flow. Rear-mounted single-plane cooling system swings up for fast service.

Designed to wear evenly so the machine provides close to 100% usage of undercarriage components, Komatsu PLUS undercarriage lowers undercarriage maintenance costs by up to 40% over a conventional undercarriage. Strengthened rollers and links increase wear life up to two times.

To provide your operation with even more versatility and adaptability, the D71 is available with an optional 36-inch wide shoe for low ground pressure applications.

Designed for your operator’s comfort and ease of use, the ergonomic, low-effort palm command control system (PCCS) joystick controls all directional movements, including machine travel speed and counter-rotation.

To help maximize operator comfort and connectivity, the D71 comes with standard Bluetooth AM/FM radio and additional AUX and USB connection capability.

Specs & Compare

Printer Friendly Version

Select up to 4 models to compare specifications

Features

OUTSTANDING VISIBILITY FOR YOUR OPERATORS

SMOOTH SHIFTING AND CONTROL

CHOOSE THE RIGHT MODE FOR THE JOB

VERSATILE AND PRODUCTIVE ADJUSTABLE BLADE

EASY-ACCESS MAINTENANCE FEATURES

LONG-LASTING UNDERCARRIAGE

READY FOR LOW GROUND PRESSURE NEEDS

COMFORTABLE, ERGONOMIC CONTROLS

BLUETOOTH/USB-COMPATIBLE RADIO
