Komatsu PC290LC-11

View Gallery

Komatsu PC290LC-11

Emission Rating

Tier 4 Final

Net Horsepower

196 HP @2,050 rpm147 kW @2,050 rpm

Max Operating Weight

72091 lb32700 kg

Max Bucket Capacity

2.13 yd³1.63 m³

Max Digging Depth

23′4″7120 mm

View All Specs

Features

Large displacement hydraulic implement pumps provide high flow output at lower engine RPM, operating at the most efficient engine speed.

Smooth operation, quick cycle times, great multi-function, while lowering fuel consumption from closed-center load-sensing hydraulic system.

Equipment designed for long-term durability with high resistance to bending and torsional stress. Booms and arms are constructed with thick plates of high tensile strength steel and designed with large cross-sectional areas.

A heavy-duty after-treatment system that combines a Komatsu Diesel Particulate Filter (KDPF) and select catalytic reduction (SCR). The system injects the correct amount of diesel exhaust fluid at the proper rate, decomposing nitrogen oxide.

Engine oil check and filter locations are integrated into one side to allow easier maintenance access. A new step provides easier access for filling the AdBlue/DEF tank.

Wide spacious cab includes a heated air suspension seat with reclining backrest. Seat height and position are easily adjusted using a pull-up lever. Armrest position easily adjusted with the console.

Updated. large, high-resolution LCD color monitor for accurate and smooth work. Key machine information displayed in user-friendly interface, rearview camera and DEF level gauge display added to default main screen.

A ROPS cab that confirms to ISO 12117-2 comes as standard equipment.

An operator identification ID can be set up for each operator and used to manage operation information of each individual machine using Komtrax data. Data can analyze operation status by operator and by machine.

Auto idle shutdown automatically shuts the engine down after idling for a set period to reduce unnecessary fuel consumption and exhaust emissions. Time before engine is shutdown can be programmed from 5 to 60 minutes.

Large heavy-duty revolving frame guards and swivel guard help protect vital components from damage and debris build-up.
